Litherra Zenith 7 Display

Total System Control. Clear System Visibility.

Note: We need info for 4 inch too. Same as this but 4 inch? Maybe resolution and tech specs are different...

The Litherra Zenith 7 Display is a high-definition 7-inch touchscreen designed to sit at the heart of the Zenith System, providing complete monitoring and control of your motorhome electrical and onboard systems. Fully compatible with all Litherra Zenith equipment, including DC-DC chargers, MPPT controllers, shunts, inverter systems, and the 12V distribution unit, Zenith 7 gives clear visibility of all power flowing into and out of the battery, allowing you to monitor system performance in real time.

When used alongside the Zenith Control Unit or the 12V distribution unit, either independently or together, it provides a powerful yet simple-to-use interface capable of managing all 12V devices, from lighting and water pumps to high-demand equipment such as Starlink and other onboard systems. The display can also show data from connected sensors, including temperatures and fluid levels in water, waste, and fuel tanks, while providing clear system fault notifications to help quickly identify and resolve issues.

Zenith 7 can be daisy-chained with the Zenith 4 Display to provide additional control points throughout the vehicle, allowing quick access to system information and controls from multiple locations. The display platform can also be customised for vehicle manufacturers, allowing branding integration and tailored system layouts to suit specific vehicle requirements.

Zenith System Compatibility & Expansion

Like all Litherra Zenith products, the Zenith 7 Display is designed to operate as part of a fully integrated and expandable system. It can be used with the Zenith Control Unit, the 12V distribution unit, or both together, depending on system requirements.

When combined with Litherra charging systems, inverter chargers, and other Zenith components, it provides full visibility of system performance, clear fault reporting, and complete monitoring of all loads and charging sources, allowing the system to expand as power demands grow while maintaining a clean and simplified installation architecture.

Technical Specifications

Display Specifications

• Screen Size 7-inch LCD
• Resolution 1024 × 600
• Brightness Adjustable
• Backlight Control Adjustable with one-key screen-off function
• Display Modes Light mode and Dark mode

User Interface Features

• Menu design Graphical
• Buttons and icons Customisable
• Control naming Customisable
• Dark and light modes Supported
• Design Industrial-grade with strong anti-interference

Communication

• Communication Method RS485
• Baud Rate 115200 bps
• Multi-screen cascading Supported
• Maximum cascade quantity Up to 6 additional displays

Electrical Specifications

• Operating Current < 600 mA
• Sleep Mode Consumption < 150 mA

Installation & Mounting

• Installation Type Panel mount or wall mount
• Protection Rating IP20

Environmental Specifications

• Operating Temperature −20°C to 70°C

Physical Specifications

• Overall Size 200.6 × 114.3 × 35.5 mm
• Panel Cut-Out Size 181.0 × 68.0 mm
