Litherra Zenith Distribution Unit

Smart Power Distribution. Protected. Connected. Expandable.

The Litherra Zenith Distribution Unit is a smart 12V power distribution system designed to safely deliver and manage power to multiple onboard devices while maintaining full system visibility and protection. With a total system capacity of 120A and 12 individually fused outputs, the unit provides reliable power distribution to essential loads such as lighting, water pumps, televisions, heating systems, and communication equipment.

Each output is protected by a plug-in fuse, and the system provides clear alerts if a fuse has blown, allowing faults to be quickly identified and resolved. Built-in protection features guard against battery overvoltage, over-discharge, load overcurrent, and high-temperature conditions, ensuring safe and dependable system operation.

Integrated Bluetooth, RS485, and CAN communication allow real-time monitoring and load control through the Zenith system, helping simplify wiring layouts while improving overall system safety and reliability.

Zenith System Compatibility & Expansion

Like all Litherra Zenith products, the Zenith Distribution Unit is designed to operate as part of a fully integrated and expandable system. When connected to the Zenith Control Unit and display system, it allows users to monitor and control individual loads while receiving real-time system alerts, including blown fuse notifications.

The unit can be used as a standalone distribution solution or integrated into larger Zenith installations, ensuring systems can expand as power demands increase while maintaining clean, organised wiring and simplified installation architecture.

Technical Specifications

Key Specifications

• Total System Capacity 120 A
• Individually Fused Outputs 12
• Blown fuse detection Alerts
• System Voltage 12 V
• Bluetooth, RS485, and CAN communication
• Protection systems Built-in
• Cooling Method Natural cooling

Electrical Specifications

• System Voltage 12 V
• Maximum Input Current 120 A
• Input Voltage Range 9–16 V
• Power Consumption ≤40 mA

Output & Load Distribution

• Number of Outputs 12 DC outputs
• Fuse Protection Individual plug-in fuse per output
• Supports Common 12 V Loads such as Lighting, Pumps, TVs and Accessories

Protection Features

• Battery Over-Voltage Protection
• Battery Over-Discharge Protection
• Load Over-Current Protection
• High-Temperature Protection

Communication Interfaces

• Bluetooth communication Supported
• RS485 communication: Supported Supported
• CAN (RV‑C protocol)

Physical Specifications

• Dimensions 263.6 × 119.8 × 48.6 mm
• Weight 1.1 kg
• Cooling Method Cooling Method: Natural cooling

Environmental Specifications

• Operating Temperature Range −35°C to 65°C
